Daewoo Puma 500 CNC Lathe, Fanuc 18iT, 35.4" Swing, 62" Centers, 12 Position ATC, 5.5" Bar Capacity, Programmable Tailstock, 2000
Make: DOOSAN DAEWOO
Model: PUMA 500
Specifications |
|||
|---|---|---|---|
| Year | 2000 | ||
| Serial Number | 450822 | ||
| # Axis | 2 | ||
| Type of CNC Control | Fanuc 18iT | ||
| Spindle Nose | A2-15 | ||
| Swing | 35.4 inches | ||
| Turning Diameter | 27.55 inches | ||
| Bar Capacity | 5.5 inches | ||
| X Axis Travel | 14.5 inches | ||
| Z Axis Travel | 62 inches | ||
| X-Axis Rapid Traverse Rate | 630 ipm | ||
| Z-Axis Rapid Traverse Rate | 790 ipm | ||
| Spindle Speed (RPM) | 1500 | ||
| Turret Capacity | 12 | ||
| Main Motor | 50 Horsepower | ||
| Tailstock | yes | ||
| Equipped With | Manual Guide I Chip Conveyor Coolant Tank & Pump Mist Collector 480-208 Transformer Collet Chuck Programmable Tailstock |
||
Be sure to call us if you're buying or selling any used CNC Lathes, Verticals, or Horizontal machinery. We have hundreds of used CNC machines at our disposal and we also specialize in used Mazak CNC machines and other brands; for example Haas, Okuma, Mori Seiki, Nakamura, Kitamura, Doosan, and Makino.
If you need any further assistance, please give us a call at 586-755-1234 to speak with one of our experienced salesman. Since we are a full used CNC dealership service, we can provide financing options, rigging, and trucking quotes. Our in-house service department reconditions and repairs all types of used CNC machinery. We can provide top dollars for your used CNC equipment or outright purchase.
Our experienced team knows the questions to ask in order to find the machine that’s right for your application. Call us today to review your requirements and get the right machine for your job. With over 75 years combined-experience and a full-service support staff we know what questions to ask to ensure you get the right equipment for the job.
